Corsair RM850x Power Supply Review: A Comprehensive Guide
In general, power supplies are the forgotten parts of computer consoles, even though they play a vital role in the stability and performance of the computer. The power supply unit (PSU) provides even and clean power to enable all the system components to operate optimally without being destroyed. The Corsair RM850x (CP-9020200-NA) is a full-modular, high-performance power supply that is well-known among game lovers and some other personal computer users. We will take an in-depth look at the Corsair RM850x review, exploring its key features, technical specifications, and real performance.
Corsair RM850x: Product Overview
The Corsair RM850x is from Corsair’s well-known series of power supplies which are appreciated for their good quality, quiet operation, and high efficiency. With a power capacity of 850 watts, it is ideal for premium gaming computers and workstations that need a consistent power supply. Having a design that is fully modular and allows its users to customize their cable management easily so that it can suit their own personal requirements, leads to a cleaner and more organized system.
Corsair RM850x: Key Features
Fully Modular Design
Corsair rm850x offers complete flexibility, allowing you to select the cables you require and remove the rest. This will ensure fewer loose wires, which will improve the machine’s cooling and cable management systems and reduce noise generation.
80 PLUS Gold Certification
Corsair rm850x is gold-certified for 80 PLUS, which means it is guaranteed to work with at least 87% efficiency under normal operating conditions. This implies that less energy would be lost through wasted heat, hence fewer electricity bills paid and reduced environmental effects.
Zero RPM Fan Mode
It includes a 135mm cooling fan that works nearly silently at low to medium loads. The Corsair rm850x feature is powered by Zero RPM Fan Mode, which means that your power supply stays silent even when you’re doing daily tasks like web browsing or streaming videos.
100% Japanese Capacitors
It uses high-quality 100% Japanese capacitors, best known for their reliability and long lifespan. These capacitors help to make sure consistent and stable power delivery, even under heavy loads.
iCUE Software Compatibility
Corsair rm850x is compatible with Corsair’s iCUE software, which allows users to monitor and control various aspects of their system, including fan speeds and power consumption.
Technical Specifications
Feature |
Details |
Model | Corsair RM850x |
Series | RMx |
Form Factor | ATX |
Power Output | 850W |
Efficiency Rating | 80 PLUS Gold |
Modularity | Fully Modular |
Cooling Fan | 135mm Rifle Bearing Fan |
Connectors | 1x 24-pin ATX, 2x 4+4-pin EPS, 6x 6+2-pin PCIe, 12x SATA,4x Molex, 1x Floppy |
Dimensions (L x W x H) | 160mm x 150mm x 86mm |
Warranty | 10 years |
Weight | 2.2 kg |
Benefits Of Corsair RM850x Power Supply
- The Corsair RM850w power supply operates with a minimum of 87% efficiency under typical load conditions thanks to the 80 PLUS Gold certification, which minimizes energy waste and lowers power bills.
- The Zero RPM Fan Mode and 135mm cooling fan work together to keep the power supply running quietly, even under heavy loads.
- Users can personalize their cable management thanks to the fully modular design, which makes the system look better and function more efficiently.
- The Corsair RM850x uses high-quality 100% Japanese capacitors, ensuring consistent and reliable power delivery to all system components.
- The 10-year warranty provides peace of mind, knowing that your investment is protected against manufacturing defects and failures.
Corsair RM850x: Packaging Contents
- Corsair RM850x Power Supply
- Modular Cables
- Power Cord
- User Manual
- Screws for mounting
Corsair RM850x: Installation Guide
Installing the Corsair RM850x is a straightforward process which can be completed in a few easy steps:
- Turn off your computer and unplug the power cord from the wall outlet.
- Open your computer case and locate an available space for the power supply.
- Remove the existing power supply (if applicable) and disconnect all cables.
- Install the RM850x in the designated space, ensuring that it is securely fastened using the included screws.
- Connect the appropriate modular cables to the corresponding system components, such as the motherboard, graphics card, and storage drives.
- Plug the power cord back into the wall outlet and turn on your computer.
Corsair RM850x: Cable Configuration
The Corsair RM850x features a wide range of connectors to serve various system configurations.
The modular cables included with the power supply are:
- 1x 24-pin ATX cable
- 2x 4+4-pin EPS cable
- 6x 6+2-pin PCIe cable
- 12x SATA cable
- 4x Molex cable
- 1x Floppy cable
- Users can choose which cables they need based on their specific system requirements, resulting in a cleaner and more organized build.
Corsair RM850x: Warranty Information
The Corsair RM850x is backed by a 10-year warranty, providing peace of mind and protection against manufacturing defects and failures. This warranty is transferable, meaning that it remains valid even if the power supply is sold to a new owner.
Corsair RM850x: Power Efficiency and Certification
The Corsair RM850x is certified as 80 PLUS Gold, which means it functions with at least 87% efficiency at regular loads. This certification follows 80 PLUS guidelines that measure power supply efficiency at different loads. Moreover, it meets the most recent ErP 2014 Lot 6 standards that demand devices not exceed 0.5W while on standby.
You may also like: H260EBM-00 Dell Power Supply Unit: A Comprehensive Review
Corsair RM850x: Troubleshooting Issues
The Corsair RM850X is quite reliable and can be trusted for efficient functioning. However, there are still some challenges that surround it, such as imperfect installation, poor cable layout, and compatibility crisis with the component. Below are some issues that explain this power supply along with their respective solutions:
Power Supply Fails to Turn On
If the power supply doesn’t turn on, ensure you’ve set the power switch on the back of your PSU to the “I” (On) position. Also, confirm that both ends of the power cord are properly connected. One end should go into a socket, while the other should go into the PSU itself. If this does not help, attempt using another outlet or resetting your PSU by unplugging it for half a minute, after which you should plug it back into the socket.
System Shuts Down or Restarts Unexpectedly
If your computer system struggles with recurring restarts, it might be due to pressure on the power supply. Make sure all cables are properly connected and your system components match the power supply’s specifications. Additionally, ensure that your system is well-ventilated and that the power supply’s cooling fan functions correctly.
Insufficient Power for System Components
Check which modular cables connect to each system component to ensure your system parts get enough power. Confirm processor data received to be equal to the minimum value provided by the manufacturer. If your system requires more than one motorized power source when shutting down or rebooting, it might have failed at some point, especially if this happens often; therefore, upgrading is mandatory.
Fan Noise or Overheating
Your power supply could be overheating due to a loud cooling fan, in that case, make sure the power supply is well-ventilated and has good airflow around it. If that doesn’t work, try replacing it with another one with better cooling options or that is more energy efficient.
Incompatibility with Motherboard or Other Components
Before connecting any components to it, make sure that the power supply is compatible with the motherboard and other system components by either reading its documents and specs or asking a technician or manufacturer.
Modular Cable Issues
To resolve connectivity glitches affecting the modular cables, ascertain they are properly attached to the power supply unit and related system components. Before replacing damaged or worn-out ones, inspect for any such signs on the cables themselves. If you are still faced with this problem, continue seeking further advice from vendors.
Software-related Issues
If you are experiencing issues with Corsair’s iCUE software, ensure that you have the latest version installed and that your system meets the minimum requirements for the software. If the issue persists, contact the manufacturer or the Corsair community for troubleshooting assistance.
You may also like: How To Choose The Best Power Supply Tester For Your Needs – A Comprehensive Guide
FAQs
How many amps is 850 watts in Corsair RM850x?
You can determine what current flows using the next formula: current equals wattage divided by voltage. Specifically, 850 watts ÷ 12 volts = 70.83 amperes.
How do you install the Corsair RM850w power supply?
Use the detailed step-by-step guide in the “Installation Guide” section to install the Corsair RM850x power supply.
How to connect the Corsair RM850x?
Connect the appropriate modular cables to the corresponding system components, such as the motherboard, graphics card, and storage drives.
Conclusion
The Corsair RM850x (CP-9020200-NA) is a power supply with best performance, it is highly efficient and operates quietly. Corsair enthusiasts and game players have a preference for Corsair RM850x power supply because it comes with 100% Japanese capacitors, a fully modular design and is compatible with Corsair’s iCUE software. In a class of its own, in terms of competitiveness for prices, it comes with a 10-year warranty, which makes the Corsair RM850w Power Supply Unit a worthy investment for anyone intending to upgrade their power supply.
